RESEARCH ON SUN LIGHT TEMPERATURE FIELD AND THERMAL DIFFERENCE EFFECT OF LONG SPAN BOX GIRDER BRIDGE WITH CORRUGATED STEEL WEBS
-
摘要: 针对目前我国桥涵设计规范未给出波形钢腹板箱梁日照温度梯度，和其温度梯度研究工作的不足。以港珠澳大桥连接线工程某特大跨波形钢腹板连续箱梁桥为研究对象，对其波形钢腹板箱室断面，进行了3 d的日照温度场观测。研究了其日照温度场分布规律，继而提出波形钢腹板箱梁竖向和横向温度梯度数学计算模型，并对温差参数的取值进行了探讨。结合现场实测数据和有限元软件，对比不同温度梯度模式的温差计算值，分析了其温差效应。研究结果表明：实测波形钢腹板箱梁温度场分布与传统箱梁相差较大；温度梯度模式为指数函数和线性函数组成的分段函数；该模式计算得到的竖向及横向温差值与实测结果十分吻合，其他模式与实测结果相差较大；由于温差效应影响，顶板中轴线下缘产生了较大的横向拉应力，设计中应给予关注。该模式可为不同气候条件地区同类桥梁温度荷载计算提供重要参考。Abstract: At present, no solar temperature gradient for the box girder with corrugated steel webs has been found in any codes for design of highway bridges and culverts of China, and the relevant research about the sun light temperature gradient is limited. With this regard, a large span continuous box girder bridge with corrugated steel webs in Hong Kong-Zhuhai-Macao Bridge was taken as an example in the paper, and three-day observation of the sun light temperature field of box girder section with corrugated steel webs was carried out, and then the distribution law of the sun light temperature field was studied. The mathematical models of vertical and lateral temperature gradient of box girders with corrugated steel webs were proposed, and the values of thermal parameters were discussed. According to the data of field test and calculation of finite element software, the values of temperature difference in different temperature gradient models were calculated and the temperature difference effect was comparatively analyzed. The research results show that the temperature field distribution of box girders with corrugated steel webs is significantly different with that of the traditional box girder. The temperature gradient model can be defined by a piecewise function composed of exponential function and linear function. The vertical and lateral temperature difference values of box girders with corrugated steel webs, which are calculated by proposed models, matched well with the measured results. Due to the temperature effect, biggish transveral stress is generated in the lower edge of the top slab around the axis, which should be paid more attention in the design. This temperature gradient pattern can be used as important reference in calculating the temperature loads of the same type bridges in different climatic conditions.
-
-
[1] 曾庆响, 韩大建, 马海涛, 等. 预应力混凝土箱梁桥的温度效应分析[J]. 中南大学学报(自然科学版), 2010, 41(6):2360-2366. Zeng Qingxiang, Han Dajian, Ma Haitao, et al. Analysis of temperature effects on prestressed concrete box girder bridges[J]. Journal of Central South University (Science and Technology), 2010, 41(6):2360-2366. (in Chinese) [2] 张元海, 李乔. 非线性日照梯度温度作用下斜支承箱梁的温度效应研究[J]. 工程力学, 2009, 26(1):131-136. Zhang Yuanhai, Li Qiao. Temperature effect on skew box girder assuming nonlinear temperature gradient of sunshine[J]. Engineering Mechanical, 2009, 26(1):131-136. (in Chinese) [3] Sallal R Abid, Nildem Taysi, Mustafa Özakça. Experimental analysis of temperature gradients in concrete box-girders[J]. Construction and Building Materials, 2016(106):523-532. [4] Lee J H, Kalkan I. Analysis of thermal environmental effects on precast prestressed concrete bridge girders:temperature differentials and thermal deformations[J]. Advances in Structural Engineering. 2012, 15(3):447-459. [5] Kim S H, Park S J, Wu J, et al. Temperature variation in steel box girders of cable-stayed bridges during construction[J]. Journal of Constructional Steel Research, 2015(112):80-92. [6] 叶见曙, 贾琳, 钱培舒. 混凝土箱梁温度分布观测与研究[J]. 东南大学学报(自然科学版), 2002, 32(5):788-793. Ye Jianshu, Jia Lin, Qian Peishu. Observation and research on temperature distribution in concrete box girders[J]. Journal of Southeast University (Natural Science Edition), 2002, 32(5):788-793. (in Chinese) [7] 方志, 汪剑. 大跨预应力混凝土连续箱梁桥日照温差效应[J]. 中国公路学报, 2007, 20(1):62-67. Fang Zhi, Wang Jian. Sun light thermal difference effect on long-span PC continuous box girder bridge[J]. China Journal of Highway and Transport, 2007, 20(1):62-67. (in Chinese) [8] 张玉平, 杨宁, 李传习. 无铺装层钢箱梁日照温度场分析[J]. 工程力学, 2011, 28(6):85-91. Zhang Yuping, Yang Ning, Li Chuanxi. Research on temperature field of steel box girder without pavement caused by the solar radiations[J]. Engineering Mechanical, 2011, 28(6):85-91. (in Chinese) [9] Reis A, Lopes N, Real P V. Shear-bending interaction in steel plate girders subjected to elevated temperatures[J]. Thin-Walled Structures, 2016(104):34-43. [10] 聂建国, 陶慕轩, 吴丽丽, 等. 钢-混凝土组合结构桥梁研究新进展[J]. 土木工程学报, 2012, 45(6):110-122. Nie Jianguo, Tao Muxuan, Wu Lili, et al. Advances of research on steel-concrete composite bridges[J]. China Civil Engineering Journal, 2012, 45(6):110-122. (in Chinese) [11] 姚伟发, 黄侨, 张娟秀. 火灾环境下钢-混凝土组合梁力学性能试验研究[J]. 工程力学, 2016, 33(8):58-65. Yao Weifa, Huang Qiao, Zhang Juanxiu. Experimental study on mechanical performance of steel-concrete girders under fire loading[J]. Engineering Mechanical, 2016, 33(8):58-65. (in Chinese) [12] 徐长武, 任志刚, 霍凯成. 太阳辐射作用下钢管膨胀混凝土界面性能试验与分析[J]. 工程力学, 2015, 32(8):201-210. Xu Changwu, Ren Zhigang, Huo Kaicheng. Experiment and analysis on interfacial performance of concrete filled steel tubes under solar radiation[J]. Engineering Mechanical, 2015, 32(8):201-210. (in Chinese) [13] 郭翔飞. 波纹钢腹板预应力混凝土箱梁温度效应研究[D]. 西安:长安大学, 2011. Guo Xiangfei. Research on temperature effect of prestressed concrete box girder with corrugated steel webs[D]. Xi'an, Chang'an University, 2011. (in Chinese) [14] 强俊涛, 姚晨, 张峰, 等. 波形钢腹板组合桥梁温度效应研究[J]. 公路, 2016, 3(3):54-57. Qiang Juntao, Yao Chen, Zhang Feng, et al. Study of temperature effect on the composed bridge with corrugated steel webs[J]. Highway, 2016, 3(3):54-57. (in Chinese) [15] AASHTO GSCBS-1989. AASHTO guide specification:thermal effects in concrete bridge superstructures[S]. Washington:America Association of State Highway, 1989. [16] JTG D60-2015, 公路桥涵设计通用规范[S]. 北京:人民交通出版社, 2015. JTG D60-2015, General code for design of highway bridges and culverts[S]. Beijing:China Communications Press, 2015. (in Chinese) [17] TB 10002.3-2005, 铁路桥涵钢筋混凝土和预应力混凝土结构设计规范[S]. 北京:中国铁道出版社, 2005. TB 10002.3-2005, Code for design on reinforced and prestressed concrete structure of railway bridge and culvert[S]. Beijing, China Railway Publishing House, 2005. (in Chinese) [18] 颜昌清, 阳先全. 混凝土薄壁箱梁横向温度应力分析[J]. 桥梁建设, 2009(3):25-28. Yan Changqing, Yang Xianquan. Analysis of transverse temperature stress of concrete thin-wall box girder[J]. Bridge Construction, 2009(3):25-28. (in Chinese) -
