火灾后型钢混凝土梁柱节点抗震性能试验研究

李俊华, 章子华, 池玉宇

李俊华, 章子华, 池玉宇. 火灾后型钢混凝土梁柱节点抗震性能试验研究[J]. 工程力学, 2017, 34(7): 156-165. DOI: 10.6052/j.issn.1000-4750.2016.02.0124
引用本文: 李俊华, 章子华, 池玉宇. 火灾后型钢混凝土梁柱节点抗震性能试验研究[J]. 工程力学, 2017, 34(7): 156-165. DOI: 10.6052/j.issn.1000-4750.2016.02.0124
LI Jun-hua, ZHANG Zi-hua, CHI Yu-yu. EXPERIMENTAL STUDY ON SEISMIC PERFORMANCE OF STEEL REINFORCED CONCRETE BEAM-COLUMN JOINTS AFTER EXPOSURE TO FIRE[J]. Engineering Mechanics, 2017, 34(7): 156-165. DOI: 10.6052/j.issn.1000-4750.2016.02.0124
Citation: LI Jun-hua, ZHANG Zi-hua, CHI Yu-yu. EXPERIMENTAL STUDY ON SEISMIC PERFORMANCE OF STEEL REINFORCED CONCRETE BEAM-COLUMN JOINTS AFTER EXPOSURE TO FIRE[J]. Engineering Mechanics, 2017, 34(7): 156-165. DOI: 10.6052/j.issn.1000-4750.2016.02.0124

火灾后型钢混凝土梁柱节点抗震性能试验研究

基金项目: 国家自然科学基金项目(51178226);浙江省自然科学基金项目(LY14E080003)
详细信息
    作者简介:

    章子华(1984-),男,浙江宁波人,副教授,工学博士,从事结构抗火抗风研究(E-mail:zhangzihua@nbu.edu.cn);池玉宇(1989-),男,浙江绍兴人,硕士生,从事结构抗火、抗震及加固修复研究(E-mail:chiyuyu@nbu.edu.cn).

    通讯作者:

    李俊华(1977-),男,湖南安仁人,教授,工学博士,从事钢与混凝土组合结构及结构抗火研究(E-mail:lijunhua@nbu.edu.cn).

  • 中图分类号: TU398+.2;TU317+.1

EXPERIMENTAL STUDY ON SEISMIC PERFORMANCE OF STEEL REINFORCED CONCRETE BEAM-COLUMN JOINTS AFTER EXPOSURE TO FIRE

  • 摘要: 通过4个火灾后型钢混凝土柱-型钢混凝土梁节点试件及2个常温未受火对比试件的低周反复加载试验,研究火灾后该类节点的滞回特性、延性、耗能性能、承载力与刚度退化规律,分析了受火时间、轴压比对火灾后该类节点的抗震性能的影响。结果表明:火灾后试件与常温未受火试件的破坏过程和破坏形态基本一致。经历火灾损伤后,型钢混凝土梁柱节点的滞回曲线仍然饱满,但试件承载力降低、变形增大、延性减弱,受火时间越长,承载力下降程度越高、变形增加程度越大、延性系数越小。反复荷载下型钢混凝土梁柱节点的强度出现衰减,加载初期的衰减系数随位移的增大而减小,加载后期的衰减系数随位移的增大总体保持稳定,体现出良好的抗荷载循环能力。与常温未受火试件相比,高温后试件加载初期的刚度降低、等效阻尼比增大,受火时间越长,刚度降低和等效阻尼比增大的程度越高。随着加载的进程,高温后试件的刚度与常温未受火时间刚度逐渐趋向一致,但等效阻尼比相比常温未受火试件减小,受火时间越长,减小程度越高。轴压比对火灾后节点的抗震性能产生一定影响,随着轴压比的增大,试件强度和刚度有所提高,但延性下降。
    Abstract: Based on cyclic reversed loading tests of four steel reinforced concrete (SRC) beam-column joints after exposure to fire and two comparative joints at ambient temperature, the hysteresis behavior, ductility, energy dissipation, load bearing capacity and stiffness degeneration of such composite joints after exposure to fire were studied. Influences of fire exposure time and axial compression ratio on seismic behavior of the samples were analyzed. Test results show that failure patterns of SRC beam-column joints after exposure to fire are similar to that at normal room temperatures. After fire damage, SRC beam-column joints have plumper hysteresis loops, lower load bearing capacity and ductility coefficient and exhibit more significant deformation. With the increase in fire exposure time, the degree of load bearing capacity degeneration and deformation increase rises, and ductility coefficients decline. Under cyclic reversed loading, the strength of SRC beam-column joints degenerates, and the degeneration coefficients decrease with the increase in displacement in the early stage of loading, but generally remain stable in the later stage of loading. This reflects good ability of resistance to cyclic loading. Compared with specimens subject to normal temperature, specimens after exposure to fire have lower initial stiffness and higher equivalent damping ratio. With the increase in fire exposure time, the degree of initial stiffness degeneration falls, and equivalent damping ratio increasing rises. With the progress of loading, the stiffness of specimens after exposure fire tends to be close and the equivalent damping ratio tends to be lower to that at normal temperature. Moreover, the degree of equivalent damping ratio decrease rises with the increase in fire exposure time at this stage. The axial compression ratio has a certain influence on the seismic behavior of SRC beam-column joints after exposure to fire. With the increase in the axial compression ratio, the strength and stiffness increase, but ductility coefficients decrease to some degree.
  • [1] 冯颖慧, 沈陶, 楼文娟, 周君. 内配圆钢管的钢骨混凝土柱火灾后剩余承载力研究[J]. 工业建筑, 2008, 38(3):16-19. Feng Yinghui, Shen Tao, Lou Wenjuan, Zhou Jun. The study of residual load bearing capacity of column reinforced by inner circular steel tube after fire[J]. Industrial Construction, 2008, 38(3):16-19. (in Chinese)
    [2] 候进学, 毛小勇. 考虑升降温作用的高温后型钢混凝土偏压柱受力性能试验研究[J]. 苏州科技学院学报(工程技术版), 2010, 23(4):21-25. Hou Jinxue, Mao Xiaoyong. An experimental investigation on behavior of eccentric compression SRC columns after fire with heating-cooling effect[J]. Journal of Suzhou University of Science and Technology:Engineering and Technology, 2010, 23(4):21-25. (in Chinese)
    [3] 毛小勇, 杜二峰, 邹大鹏. 型钢混凝土柱抗火全过程分析[J]. 哈尔滨工业大学学, 2009, 41(增刊2):215-218. Mao Xiaoyong, Du Erfeng, Zou Dapeng. Numerical analysis of SRC columns under fire including temperature rise period and drop period[J]. Journal of Harbin Institute of Technology, 2009, 41(Suppl 2):215-218. (in Chinese)
    [4] Du E F, Shu G P, Mao X Y. Analytical behavior of eccentrically loaded concrete encased steel columns subjected to standard fire including cooling phase[J]. International Journal of Steel Structures, 2013, 13(1):129-140.
    [5] 谭清华, 韩林海. 火灾后和加固后型钢混凝土柱的力学性能分析[J]. 清华大学学报(自然科学版), 2013, 53(1):12-17. Tan Qinghua, Han Linhai. Post-fire and poststrengthening analysis of steel reinforced concrete columns subjected to fire[J]. Journal of Tsinghua University (Science & Technology), 2013, 53(1):12-17. (in Chinese)
    [6] 王广勇, 谢福娣, 张东明, 郑蝉蝉. 火灾后型钢混凝土柱抗震性能试验及参数分析[J]. 土木工程学报, 2015, 48(7):60-70. Wang Guangyong, Xie Fudi, Zhang Dongming, Zheng Chanchan. Test and parametric analysis on post-fire seismic performance of steel reinforced concrete columns[J]. Chinese Civil Engineering Journal, 2015, 48(7):60-70. (in Chinese)
    [7] 王广勇, 史毅, 张东明, 郑蝉蝉. 火灾后型钢混凝土柱抗震性能试验研究[J]. 工程力学, 2015, 32(11):160-169. Wang Guangyong, Shi Yi, Zhang Dongming, Zheng Chanchan. Experimental research on post-fire seismic performance of steel reinforced concrete columns[J]. Engineering Mechanics, 2015, 32(11):160-169. (in Chinese)
    [8] 李俊华, 刘明哲, 唐跃峰, 郑荣跃. 火灾后型钢混凝土梁受力性能试验研究[J]. 土木工程学报, 2011, 44(4):84-90. Li Junhua, Liu Mingzhe, Tang Yuefeng, Zheng Rongyue. Experimental study on the mechanical properties of steel reinforced concrete beams after exposure to fire[J]. Chinese Civil Engineering Journal, 2011, 44(4):84-90. (in Chinese)
    [9] 李俊华, 唐跃峰, 刘明哲. 火灾后型钢混凝土柱受力性能试验研究[J]. 建筑结构学报, 2012, 33(2):56-63. Li Junhua, Tang Yuefeng, Liu Mingzhe. Experimental study on mechanical properties of steel reinforced concrete columns after exposure to fire[J]. Journal of Building Structures, 2012, 33(2):56-63. (in Chinese)
    [10] 李俊华, 刘明哲, 萧寒. 火灾后型钢混凝土梁剩余承载力数值模拟分析[J]. 西安建筑科技大学学报(自然科学版), 2013, 45(4):470-478. Li Junhua, Liu Mingzhe, Xiao Han. Numerical simulating analysis for residual load bearing capacity of steel reinforced concrete beams after exposure to fire[J]. Journal of Xi'an University of Architecture and Technology (Natural Science Edition), 2013, 45(4):470-478. (in Chinese)
    [11] 唐跃锋, 李俊华, 孙彬. 火灾后型钢混凝土柱剩余承载力数值模拟分析[J]. 工程力学, 2014, 31(增刊):91-98. Tang Yuefeng, Li Junhua, Sun Bin. Numerical simulating analysis for residual load bearing capacity of steel reinforced concrete columns after exposure to fire[J]. Engineering Mechanics, 2014, 31(Suppl):91-98. (in Chinese)
    [12] 李俊华, 邱栋梁, 俞凯, 孙彬. 高温后型钢混凝土粘结滑移性能研究[J]. 工程力学, 2015, 32(2):190-200, 206. Li Junhua, Qiu Dongliang, Yu Kai, Sun Bin. Study on bond-slip behavior between shaped steel and concrete in SRC structures after exposed to high temperature[J]. Engineering Mechanics, 2015, 32(2):190-200, 206. (in Chinese)
    [13] 李俊华, 陈建华, 孙彬. 高温后型钢混凝土柱抗震性能试验研究[J]. 建筑结构学报, 2015, 36(5):124-132. Li Junhua, Chen Jianhua, Sun Bin. Experimental study on seismic performance of steel reinforced concrete columns after exposure to fire[J]. Journal of Building Structures, 2015, 36(5):124-132. (in Chinese)
    [14] Song T Y, Han L H, Yu H X. Temperature field analysis of SRC-column to SRC-beam joints subjected to simulated fire including the cooling phase[J]. Advances in Structural Engineering, 2011, 14(3):353-366.
    [15] Han Linhai, Tan Qinghua, Song Tianyi. Fire performance of steel reinforced concrete (SRC) structures[J]. Procedia Engineering, 2013, 62:46-55.
    [16] Song Tianyi, Han Linhai, Tao Zhong. Structural behavior of SRC beam-to-column joints subjected to simulated fire including cooling phase[J]. Journal of Structural Engineering, 2015, 141(9):1-12.
    [17] 李俊华, 马超, 陈建华, 钱钦. 火灾后型钢混凝土柱-钢梁节点抗震性能试验研究[J]. 防灾减灾工程学报, 2015, 35(1):51-56. Li Junhua, Mao Chao, Chen Jianhua, Qian Qin. Experimental research on seismic behavior of steel reinforced concrete column-steel beam joints after exposure to fire[J]. Journal of Disaster Prevention and Mitigation Engineering, 2015, 35(1):51-56. (in Chinese)
