三面受火的内配型钢方钢管混凝土柱火灾全过程分析

毛文婧, 王文达, 王景玄

毛文婧, 王文达, 王景玄. 三面受火的内配型钢方钢管混凝土柱火灾全过程分析[J]. 工程力学, 2016, 33(增刊): 143-149. DOI: 10.6052/j.issn.1000-4750.2015.05.S011
引用本文: 毛文婧, 王文达, 王景玄. 三面受火的内配型钢方钢管混凝土柱火灾全过程分析[J]. 工程力学, 2016, 33(增刊): 143-149. DOI: 10.6052/j.issn.1000-4750.2015.05.S011
MAO Wen-jing, WANG Wen-da, WANG Jing-xuan. PERFORMANCE ANALYSIS OF CONCRETE-FILLED SQUARE STEEL TUBULAR COLUMNS WITH INTERNAL PROFILED STEEL UNDER THREE-FACE FIRE CONDITIONS[J]. Engineering Mechanics, 2016, 33(增刊): 143-149. DOI: 10.6052/j.issn.1000-4750.2015.05.S011
Citation: MAO Wen-jing, WANG Wen-da, WANG Jing-xuan. PERFORMANCE ANALYSIS OF CONCRETE-FILLED SQUARE STEEL TUBULAR COLUMNS WITH INTERNAL PROFILED STEEL UNDER THREE-FACE FIRE CONDITIONS[J]. Engineering Mechanics, 2016, 33(增刊): 143-149. DOI: 10.6052/j.issn.1000-4750.2015.05.S011

三面受火的内配型钢方钢管混凝土柱火灾全过程分析

基金项目: 国家自然科学基金项目(51468037);甘肃省委组织部"陇原青年创新人才扶持计划"项目
详细信息
    作者简介:

    毛文婧(1990-),女,甘肃人,博士生,主要从事内配型钢的钢管混凝土构件受火性能的研究(E-mail:cemaowj@163.com);王景玄(1986-),男,甘肃人,博士生,主要从事钢管混凝土结构抗火及抗连续性倒塌性能的研究(E-mail:cewangjx@163.com).

    通讯作者:

    王文达(1976-),男,甘肃人,教授,博士,从事钢与混凝土组合结构、混合结构及结构抗火性能的研究(E-mail:wangwd@lut.cn).

  • 中图分类号: TU398.9

PERFORMANCE ANALYSIS OF CONCRETE-FILLED SQUARE STEEL TUBULAR COLUMNS WITH INTERNAL PROFILED STEEL UNDER THREE-FACE FIRE CONDITIONS

  • 摘要: 采用有限元软件ABAQUS建立了标准火灾作用下内配型钢方钢管混凝土柱的热力耦合模型,并与已有的试验进行了对比和验证。计算了该类构件在火灾全过程作用下的荷载-轴向位移、荷载-跨中侧向位移的关系曲线,分析了该类构件在常温加载、升温、降温、火灾后再加载四个阶段的应力变化情况,并将强轴和弱轴两种加载方式下的结果进行了对比。在此基础上,对影响火灾后剩余承载力影响系数的主要参数进行了分析。结果表明:火灾荷载比、升温时间比、长细比等因素对该类构件火灾后剩余承载力有较显著的影响。
    Abstract: A finite element (FE) model of concrete filled square steel tubular column with internal profiled steel under standard fire conditions was developed using ABAQUS software. The FE model was verified with experimental results. The loading versus axial displacement curves were calculated in overall stage fire conditions, and loading versus lateral displacement curves were also studied. The stress distribution was analyzed in loading at the ambient stage, heating stage, cooling stage, and post fire stage. The results under loading at major axis and secondary axis were compared. The main parameters that affected the residual bearing capacity coefficients after exposure to full stage fire conditions were analyzed. The results show that the fire loading ratio, fire duration time ratio, and the slenderness ratio of column have significant effect on the residual bearing capacity.
  • [1] 毛小勇, 高伟华, 李丽丽, 等. 三面受火型钢混凝土柱耐火极限试验研究[J]. 自然灾害学报, 2010, 19(6): 93-99. Mao Xiaoyong, Gao Weihua, Li Lili, et al. Experimental study on fire resistance of steel reinforced concrete columns subjected to 3-side heating[J]. Journal of Natural Disasters, 2010, 19(6): 93-99. (in Chinese)
    [2] Song T Y, Han L H, Yu H X. Concrete filled steel tube stub columns combined temperature and loading[J]. Journal of Constructional Steel Research, 2010, 66(3): 369-384.
    [3] 吕学涛, 杨华, 张素梅. 三面受火的方钢管混凝土柱的耐火极限[J]. 自然灾害学报, 2012, 21(3): 198-203. Lü Xuetao, Yang Hua, Zhang Sumei. Fire resistance limit of concrete-filled square steel tube columns exposed to three-faced fire[J]. Journal of Natural Disasters, 2012, 21(3): 198-203. (in Chinese)
    [4] 杨华, 刘发起, 吕学涛, 等. 三面受火的矩形钢管混凝土柱受力机理与耐火极限[J]. 建筑钢结构进展, 2011, 13(6): 56-63. Yang Hua, Liu Faqi, Lü Xuetao, et al. Mechanism and fire resistance of concrete-filled RHS columns in three-surface fire[J]. Progress in Steel Building Structures, 2011, 13(6): 56-63. (in Chinese)
    [5] 谭清华, 韩林海, 周侃. 火灾下型钢混凝土柱的受力全过程分析[J]. 防灾减灾工程学报, 2015, 35(1): 63-68. Tan Qinghua, Han Linhai, Zhou Kan. Full-range analysis of steel reinforced concrete column subjected to fire[J]. Journal of Disaster Prevention and Mitigation Engineering, 2015, 35(1): 63-68. (in Chinese)
    [6] Xu L, Liu Y B. Concrete filled steel tube reinforced concrete (CFSTRC) columns subjected to ISO-834 standard fire experiment[J]. Advances in Structural Engineering, 2013, 16(7): 1263-1282.
    [7] 肖会霞, 王景玄, 王文达. 三面受火的方钢管混凝土柱火灾全过程力学性能分析[J]. 防灾减灾工程学报, 2015, 35(1): 100-106. Xiao Huixia, Wang Jingxuan, Wang Wenda. Analysis of mechanical performance of concrete-filled square hollow section columns exposed to three-surface fire[J]. Journal of Disaster Prevention and Mitigation Engineering, 2015, 35(1): 100-106. (in Chinese)
    [8] 韩祎, 王景玄, 王文达. 内配型钢方钢管混凝土偏压构件受火全过程数值模拟[J]. 工程力学, 2015, 32(增刊): 60-65, 90. Han Yi, Wang Jingxuan, Wang Wenda. Numerical simulation analysis on concrete-filled square steel tubular columns with internal profiled steel under eccentric compression exposure to full-range fire[J]. Engineering Mechanics, 2015, 32(Suppl): 60-65, 90. (in Chinese)
    [9] 韩林海. 钢管混凝土结构-理论与实践[M]. 第2版. 北京: 科学出版社, 2007: 539-546. Han Linhai. Concrete filled steel tubular structure-theory and practice[M]. 2nd ed. Beijing: Science Press, 2007: 539-546. (in Chinese)
    [10] 林晓康, 韩林海. 火灾后圆钢管混凝土柱荷载-位移滞回性能研究[J]. 建筑结构学报, 2005, 26(3): 19-29. Lin Xiaokang, Han Linhai. Loading-displacement hysteretic of concrete filled CHS columns after exposure to ISO-834 standard fire[J]. Journal of Building Structures, 2005, 26(3): 19-29. (in Chinese)
    [11] 王景玄, 王文达. 不同火灾工况下钢梁-钢管混凝土柱平面框架受火全过程分析[J]. 建筑结构学报, 2014, 35(3): 102-109. Wang Jingxuan, Wang Wenda. Analysis of planar frame with steel beam-concrete-filled steel tubular columns after exposure to complete fire process under different fire cases[J]. Journal of Building Structures, 2014, 35(3): 102-109. (in Chinese)
