复合材料正交加筋层合圆柱壳结构阶梯式挖补修理的参数化研究

李顶河, 赵鲁春, 徐建新, 卿光辉

李顶河, 赵鲁春, 徐建新, 卿光辉. 复合材料正交加筋层合圆柱壳结构阶梯式挖补修理的参数化研究[J]. 工程力学, 2012, 29(9): 308-317. DOI: 10.6052/j.issn.1000-4750.2010.12.0873
引用本文: 李顶河, 赵鲁春, 徐建新, 卿光辉. 复合材料正交加筋层合圆柱壳结构阶梯式挖补修理的参数化研究[J]. 工程力学, 2012, 29(9): 308-317. DOI: 10.6052/j.issn.1000-4750.2010.12.0873
LI Ding-he, ZHAO Lu-chun, XU Jian-xin, QING Guang-hui. PARAMETRIC INVESTIGATION OF ORTHOTROPIC STIFFENED COMPOSITE LAMINATED CYLINDRICAL SHELLS WITH A STEPPED-LAP REPAIR[J]. Engineering Mechanics, 2012, 29(9): 308-317. DOI: 10.6052/j.issn.1000-4750.2010.12.0873
Citation: LI Ding-he, ZHAO Lu-chun, XU Jian-xin, QING Guang-hui. PARAMETRIC INVESTIGATION OF ORTHOTROPIC STIFFENED COMPOSITE LAMINATED CYLINDRICAL SHELLS WITH A STEPPED-LAP REPAIR[J]. Engineering Mechanics, 2012, 29(9): 308-317. DOI: 10.6052/j.issn.1000-4750.2010.12.0873

复合材料正交加筋层合圆柱壳结构阶梯式挖补修理的参数化研究

基金项目: 国家自然科学基金民航联合研究基金项目(60979001);中国民航大学校级重大项目(CAUA2009ZD0101);中国民航大学校级科研基金项目(2011KYE03)
详细信息
    作者简介:

    赵鲁春(1987―),女,陕西人,硕士生,从事飞机复合材料结构修理技术研究(E-mail: zhaoluchun1987@sina.com);徐建新(1967―),男,江苏人,教授,博士,从事飞机复合材料结构设计、复合材料疲劳研究(E-mail: jianxin_xu@eyou.com);卿光辉(1968―),男,湖南人,副教授,博士,从事飞机复合材料力学性能分析、复合材料结构设计研究(E-mail: qingluke@126.com).

    通讯作者:

    李顶河(1983―),男,湖北人,助教,硕士,从事飞机复合材料结构修理技术与理论研究(E-mail: lidinghe@163.com).

  • 中图分类号: TB332

PARAMETRIC INVESTIGATION OF ORTHOTROPIC STIFFENED COMPOSITE LAMINATED CYLINDRICAL SHELLS WITH A STEPPED-LAP REPAIR

  • 摘要: 利用三维参数化有限元分析模型,对复合材料正交加筋层合圆柱壳结构的阶梯式挖补修理进行了参数分析.主要考虑了载荷情况、阶梯数、铺层顺序以及补片铺层错误等修理参数对阶梯式挖补修理结构胶层剥离应力和剪切应力分布情况的影响规律,并利用绝对值的平均值和均方差来描述胶层剪切应力剥离应力的分布情况,以确定最优的阶梯式挖补修理参数.基于该文建立的三维有限元模型可以深入地了解复合材料正交加筋层合圆柱壳结构阶梯式挖补修理区域胶层应力分布的详细情况,而且参数化分析结论也可为复合材料正交加筋层合板圆柱壳结构的阶梯式挖补修理方案的设计和分析提供参考.
    Abstract: Based on three-dimensional parametric finite element (FE) models, the parametric investigation was carried out for the orthotropic stiffened composite laminated cylindrical shell with a stepped-lap repair. The influences of the parameters of bonding on the distributions of the peel stress and shear stress of the adhesive were studied, such as load conditions, number of steps, stacking of sequence and mismatch adherend lay-ups. The mean of absolute values and average variance were used to measure the distributions of the peel stress and shear stress of the adhesive. And the optimal parameters of the stepped-lap repair can be determined by this scheme. A three dimensional FE model of this investigation provides further insight into the stresses developed in the stepped-lap repair of the orthotropic stiffened composite laminated cylindrical shell under loading. The results of this parametric investigation may lead to improve design and analysis technique of the stepped-lap repair in the orthotropic stiffened composite laminated cylindrical shell.
  • [1] Baker A A, Chester R I, Hugo G R, Radtke T C. Scarfrepairs to highly strained graphite/epoxy structure [J].International Journal Adhesion & Adhesive, 1999, 19:161-171.

    [2] Bartholomeusz R A, Baker A A, Chester R I, Searl A.Bonded joints with through-thickness adhesive stressesreinforcing the F/A Y470.5 bulkhead [J]. InternationalJournal Adhesion & Adhesive, 1999, 19: 173-180.

    [3] Chalkley P, Baker A A. Development of a generic repairjoint for certification of bonded composite repairs [J].International Journal Adhesion & Adhesive, 1999, 19:121-132.

    [4] Oplinger D. Effects of adherend deflections in single lapjoints [J]. International Solids and Structures, 1994, 1:2565-2587.

    [5] Naboulis S, Mall S. Nonlinear analysis of bondedcomposite patch repair of cracked aluminum panels [J].Composite Structures, 1998, 41: 303-313.

    [6] Kaye R, Heller M. Finite element-basedthree-dimensional stress analysis of composite bondedrepairs to metallic aircraft structure [J]. InternationalJournal of Adhesion & Adhesives, 2006, 26(4): 261-273.

    [7] Alex B. Harman, Chun H. W. Improved design methodsfor scarf repairs to highly strained composite aircraftstructure [J]. Composite Structures, 2006, 75(1/2/3/4):132-144.

    [8] Hart Smith L J. Adhesive-bonded scarf and stepped-lapjoints [C]. Hampton, VA: Langley Research Center,NASA CR 112237, 1973.

    [9] Webber J P H. Scarf repair joints in carbon fiberreinforced plastic strips [J]. Journal of Adhesion, 1981,12(4): 257-281.

    [10] Pipes R B, Adkins D W. Strength and mechanics ofbonded scarf joints for repair of composite materials [R].Delaware University, Newark. Center for CompositeMaterials, NAS 1.26: 169708, 1982.

    [11] Tsai M Y, Oplinger D W, Morton J. Improved theoreticalsolutions for adhesive lap joints [J]. International JournalSolid Structure, 1998, 35: 1163-1185.

    [12] Mortensen F, Thomsen O T. Analysis of adhesivebonded joints: a unified approach [J]. Composite ScienceTechnology, 2002, 62: 1011-1031.

    [13] Zou G P, Shahin K, Taheri F. An analytical solution forthe analysis of symmetric composite adhesively bondedjoints [J]. Composite Structure, 2004, 65(3/4): 499-510.

    [14] Odi R A, Friend C M. An improved 2D model forbonded composite joints [J]. International Journal ofAdhesive, 2004, 24(5): 389-405.

    [15] Soutis C, Hu F Z. A 3D failure analysis of scarf patchrepaired CFRP plates [C]. Proceedings of the 39thAIAA/ASME/ASCE/AHS/ASC Structures, StructuralDynamics and Materials Conference, 1998, Part 1 (of 4):1971-1977.

    [16] Fredrickson B M, Schoeppner G A, Mollenhauer D H.Application of three-dimensional spline variationalanalysis for composite repair [J]. Composite Structures,2008, 83(2): 119-130.

    [17] Duong C N, Wang C H. Composite repair: theory anddesign [M]. Netherlands: Elsevier, 2007: 421-441.

    [18] Chukwujekwu A, Bhogapurapu Hari. Design andanalysis of adhesively bonded thick composite patchrepair of corrosion grind-out and cracks on 2024T3 cladaluminum aging aircraft structures [J]. CompositeStructures, 2006, 76(3): 138-150.
